Top 10 Screen Printing Machine

As a professional screen printing machine manufacturer, Once is committed to providing customers with excellent and the best screen printing machines. ONCE has a highly skilled and experienced technological research and development team. At the same time, it can design products that satisfy customers according to their requirements. With years of experience in screen printer machine production, ONCE has won praises for its exceptional quality and has quickly dominated the market.

Now you will learn the top 10 screen print machines that are popular in user experience. You have reached the right place if you’re looking for the best machine. We can help you select the best screen printing machine to suit your needs. Let’s have a look at the 10 best screen printing machines.

What’s the Best Screen Printing Machine

For most people, buying a screen print machine means spending years of savings. So this is a long-term investment. It is very necessary to choose the best screen printing machine. If you are on a budget, then a single-color silk screen printing machine will suffice. If you have enough budget, then an expensive screen printer machine will definitely bring you an unparalleled experience. Its performance is incomparable to cheaper machines. Of course, what suits you is the best.

Top 1 One Color Automatic UV Silk Screen Bottle Printing Machine

ONCE, a bottle printing machine manufacturer offers a print testing service for client bottles samples so that you can verify the quality of the print before placing your order.

OS-767-1C is a fully automatic UV curing single-color screen printing bottle machine, also commonly known as a single-color bottle UV screenprinting machine. It can be used to print round, oval, and square bottles. Such as metal bottles, plastic bottles, and glass bottles. One of the biggest advantages of this 1 color automatic screen printing machine is the fast printing speed, which can print 4200 bottles per hour.

Specifications of This Bottle Screen Printing Machine

Model NO.: OS-767-1C
Round container size: Diameter: φ10-100mm, Height: 30-260mm
Round container max. print area: L 260 x W220mm
Oval container size: R: 10-250mm, Height: 30-260mm
Oval container max. print area: L 120 x W220mm
Drive: Mechanical Driven
Control system: OMRON PLC & Touch Screen
Max. printing capacity: 70 pcs/min
Registration tolerance: +/- 0.2 mm
Infeed conveyor: 1 unit, length: 2 meters
Deionizing device: 1 unit
Flame treating system: 1 unit, LP gas
Motor: ITALY MOTOVARIO
Print head: 1 unit
UV system: 1 unit intelligent UV system, 5KW per each
Outfeed conveyor: 1 unit, Length: 2 meters
Frequency Converter: OMRON
Pneumatic parts: FESTO or SMC
Electrical: 380V 3phase 50Hz
Air requirement: 5-7 bar
Air consumption: 85 liter/ minute max. (per color)
Power consumption: 5.4 KW/color x 1
Machine size(LxWxH): Main machine: 2300x1800x1700mm
Weight: 1600 KG

Four Reasons Why This Screen Print Machine Sells Well:

  • High Speed

The printing speed is up to 4200 bottles per hour, 22 pieces per minute.

  • Print Diversity

Can be printed on the square, round and oval bottles.

  • High Stability

Mechanically driven bottle conveying with high stability.

  • Low Consumption

A smart UV system reduces energy consumption.

Top 2 One Color Automatic Cosmetic Tube Screen Printing Machine

OS-175 can provide you with an unparalleled power experience. It is a 1 color automatic UV screenprinting machine. Suitable for screen printing on flexible or rigid plastic tubes, plastic cans. As long as your container is a cylinder up to 75mm in diameter. The configuration of the OS-175 is quite complete. Including the main drive motor produced in Europe, the intelligent UV curing device, and the feeding belt.

Specifications of This Tube Screen Printing Machine

Model NO.: OS-175
Print product size (DiameterxLength): Ø10mm-Ø75mm, L: 20mm-230mm
Max. print area: 236x170mm
Max. printing speed: 60-80 pcs/min
Registration tolerance: +/- 0.2
Drive: Mechanical driven
Control system: OMRON PLC & Touch Screen
Stations: 12 stations
Deionizing device: 1 unit
Flame treating system: 1 unit
Print head: 1 unit
UV system: 1 unit intelligent UV system
UV lamp power: 3.6 KW
Main Motor: ITALY MOTOVARIO
Pneumatic parts: Japan SMC
Photoelectric Sensor: Japan Keyence
Frequency Converter: Japan OMRON
Indexer Japan SANKYO
Electrical Supply: 380V/480V 3phase 50Hz/60Hz
Air requirement: 6-8 bar
Power consumption: 4.5 KW
Machine Dimension (LxWxH): 1500x1180x1900mm
Weight: 1500 KG

Six Reasons Why This Screen Printer Machine Sells Well:

  • High-speed vertical rotary UV screen printing machine.
  • Print speed up to 80ppm.
  • The blade angle and height can be adjusted.
  • Setup and transitions are quick and easy.
  • Equip with flame treatment and deionizing device.
  • Has a mechanically synchronized print head for precise printing.

Top 3 Multicolor Semi-Automatic Round Bottle Screen Printing Machine

This economical standard round bottle press is one of the most popular. OS-400S is capable of multi-color printing. It can print up to 110mm in diameter and easily convert different size bottles on the programmable touch screen. The maximum printing area can reach L350xH220mm. It can print a variety of round containers, such as plastic and metal bottles. Also, it has servo-driven printing and motor-driven up and down strokes. A programmable PLC touch screen controls all actions, not only fast but also stable printing.

Specifications of This Bottle Screen Printing Machine

Model NO.: OS-400S
Print shape Round
Up & Downstroke Driven: Electric motor
Print stroke Driven: Servo motor
Re-registration system: Servo motor & Optical sensor
Control system: Brand PLC & Touch Screen
Print round diameter: Ø7mm(0.276″)-Ø110mm (4.33″)
Maximun print area: L350mm x H220 mm
Maximum screen frame size: 800 x 400mm (31.50″ x 15.74″)
Printing cycle speed: 2000 cycles/hour
Registration tolerance: +/- 0.3-0.5 mm (except products tolerance)
Electrical supply: 110V/220V 50-60Hz 2.5KW
Air requirement: 5-7 bar
Machine dimension: L900 x W800 x H1450 mm
Weight: 200 kg (440.92 lbs)

Five Reasons Why This Screenprinting Machine Sells Well:

  • Simple tool changes can be implemented quickly.
  • Optical sensor from Germany with high reading accuracy.
  • Multi-color printing is possible, suitable for different kinds of containers.
  • Programmable PLC and touch screen.
  • Scraper inclination angle and height are adjustable.

Top 4 Semi-Automatic Round Bottle Screen Printing Machine

OS-400 is a well-designed multifunctional semi-automatic cylinder screen printing machine. The maximum printing diameter of this machine is 110mm. It is a printing machine specially used for round and oval objects such as bottles and cups. Easy-to-operate PCB board controls, precise mechanical registration, and a pneumatic drive system make this circular screen printer the perfect all-purpose screen-printer. Print speeds of up to 1,200 parts per hour with a simple die changeover.

Specifications of This Bottle Screen Printing Machine

Model Number: OS-400
Drive System: Pneumatic
Frame Up/Down Stroke: 100mm (3.94″)
Maximum Print Area Round: Maximum Print Area Oval: Maximum Print Area Flat: 110mm (4.33″) Ø340mm (13.39″) Arc Length 200 x 320mm (7.87″ x 12.60″)
Working Table Size: 250 x 350mm (9.84″ x 13.78″)
Table Adjustment: X,Y ± 15mm / θ 15 °
Maximum Screen Frame Size: 380 x 580mm (14.96″ x 22.83″)
Screen Frame Thickness: 18 – 25mm (0.71″ -0.98″)
Squeegee Angle: 0-15°
Printing Cycle Speed: 1,200 cycles/hr
Squeegee Speed: 20/min
Squeegee Pressure: 2 – 4 Bar
Electric Source: 110V/220V 50-60Hz 50W
Air Pressure Input: 80 psi
Air Consumption: 0.7 L/cycle
Machine Weight: 150 kg (330.69 lbs)
Machine Weight (including crating): 230 kg (507.06 lbs)
Dimensions (L x W x H): 1,000 x 950 x 1,400mm
Crate Dimensions: 1,080 x 1,010 x 1,520mm

Five Reasons Why This Screen Print Machine Sells Well:

  • With shock absorbers, pneumatically controlled.
  • The screen frame angle and tilt are adjustable.
  • Easy-to-operate PCB board controls.
  • Vertical lift with adjustable height.
  • With X/Y/R positioning pendant table.

Top 5 Three Color Automatic Flat Bed Screen Printing Machine

This UV screen printing machine is fully automated and can be used on flat surfaces. It has high production efficiency. The ink is automatically cured by high-power UV lamps. UV lamps are located behind each printing station. And the OS-R324 is equipped with a SITI main drive motor as well as a US-made UV curing unit and a high-intensity mercury UV bulb. There is a pre-flame treatment station and deionization. This ensures high-quality print results and fewer errors. Once provides tools such as flat pens, printing dressing boxes, stationery rulers, etc.

Specifications of This Flat Bed Screen Printing Machine

Model NO.: OS-F324
Print product size: L160 x W160 x H100 mm
Max. print area: L110 x W90 mm
Max. printing speed: 45 pcs/min
Drive: Mechanical driven
Flame treating system: 1 unit
Print head: 3 units
Stations: 24 stations
UV system: 3 units electronic UV system, 5KW per each
Deionizing device: 1 unit
Motor: ITALY SITI
Control system: OMRON PLC & Touch Screen
Pneumatic parts: Japan SMC
Electrical supply: 380V/480V 3phase 50Hz/60Hz
Air requirement: 6-8bar
Power consumption: 10 KW
Machine dimension: L4950 x W3150 x H2350 mm
Weight: 1500 KG

Six Reasons Why This Automatic Screen Printing Machine Sells Well:

  • Automatic loading and unloading system.
  • Quick and easy conversion system.
  • The scraper angle and height are adjustable.
  • Print area: 110 x 90 mm (4.33 in x 3.54 in).
  • U.S.-made UV curing unit.
  • Print speed up to 45ppm.

Top 6 OS Series Electric Flat Screen Printing Machine

OS series flatbed silk screen printing machines are widely used in industrial product printing, paper printing, graphic printing, glass printing, etc. There are several different models of flatbed screen printing machines in this series. Each model prints at a different size. Such as 300x500mm, 400x600mm, 600x900mm, 700x1200mm, and even larger sizes. This range of flat-screen printers is ideal for printing graphic panels, overlays, membrane switches, and transfer papers of all sizes. In addition, flat vertical lifting enables operators to easily load and unload parts and easily inspect printed parts during operation.

Specifications of This Electric Flat Bed Screen Printing Machine

Model OS-3050V OS-4060V OS-5070V OS-6090V OS-70120V
Frame up/down stroke 150mm 200mm 200mm 200mm 200mm
Print stroke(left&right) 550mm 700mm 800mm 1000mm 1300mm
Max print area 300x500mm 400x600mm 500x700mm 600x900mm 700x1200mm
Vacuum table size 300x500mm 400x600mm 500x700mm 600x900mm 700x1200mm
Working table size 350x600mm 500x700mm 600x800mm 700x1000mm 800x1300mm
Max frame size 500x830mm 600x9300mm 700x1130mm 800x13000mm 1000x14500mm
Screen frame thickness 50.8mm
Squeegee pressure 2-4 bar
Max print speed 1,200 cycles/hr 800 cycles/hr 800 cycles/hr 800 cycles/hr 600 cycles/hr
Electric source 110/220/230V 50/60Hz 110/220/230V 50/60Hz 110/220/230V 50/60Hz 380V 50/60Hz 380V 50/60Hz
Machine weight 190kg 320kg 380kg 660kg 680kg
Machine dimension 800x1050x1550mm 1150x1000x1700mm 1100x1300x1650mm 1350x1350x1700mm 1450x1650x1700mm

Five Reasons Why This Machine Sells Well:

  • Stable and durable.
  • With the emergency stop button.
  • Footswitch control.
  • Touch screen control is programmable and easy to operate.
  • The dual-axis AC motor drive can realize horizontal and vertical work.
