Introduction:
AP-1200 is a semi-automatic screen printer designed for printing onto large pails, 20 litre buckets and 4 litre sized plastic bottles. The AP-1200 jumbo screen printing press can also screen print on glass wine bottles (750ml, Magnum, Double Magnum, Jeroboam, Reboboam and Imperial), beer bottles, beer pony kegs, stainless-steel thermos bottles, jars & containers. The AP-1200 features quick & simple tooling changeovers, precise mechanical registration & conveniently all controls are on the touch screen, making the AP-1200 the perfect all around universal jumbo screen printing press for large objects.
Features:
Electric motor drove left and right stroke.
Microprocessor controlled – PLC
Vertical part lift with height adjustment
Print stroke controlled with electric motor
X/Y/R positioning ware-mounting table
Linear ball bearings on hardened shafts
Squeegee tilt, skew, and height adjustable
Screen frame angle & tilt adjustable
Synchronized bottle inflation system with regulator
Regulated squeegee pressure with pressure gauge
Floor levelers & casters
Foot switch controlled
Specifications:
| Model NO.: | AP-1200 |
| Drive System: | Electric motor |
| Frame Up/Down Stroke: | 100mm (4″) |
| Maximum Print Area Round: Maximum Print Area Oval: | Ø 350mm 1,090mm Arc Length |
| Maximum Screen Frame Size: | 900 x 1,600mm (35.43″ x 55.12″) |
| Screen Frame Thickness: | 18 – 25mm (.71″ – .98″) |
| Squeegee Angle: | 0-15° |
| Printing Cycle Speed: | 680 cycles/hour |
| Squeegee Speed: | 13/min |
| Squeegee Pressure: | 2-4 Bar |
| Electric Source: | 110V/220V 50-60Hz 50W |
| Air Pressure Input: | 80 psi |
| Machine Weight: | 277 kg (610.68 lbs) |
| Machine Weight (including crating): | 407 kg (897.28 lbs) |
| Dimensions (L x W x H): | 1,750 x 900 x 1,700mm |
| Crate Dimensions: | 1,900 x 1,100 x 1,850mm |
