Introduction:
AP-600 Semi auto round screen printing machine is a well designed and versatile round screen printing machine.
The AP-600 screen bottle printer can screen print on glass bottles, plastic water bottles, cosmetic tubes, aluminum water bottles, drum sticks, glass pipettes, etc.
The AP-600 features quick & simple tooling changeovers, precise mechanical registration & conveniently all controls are on the front panel, making the AP-600 the perfect all around universal screen printing press.
Features of Semi Auto Round Screen Printing Machine:
Pneumatic controlled with shock absorbers
Microprocessor controlled – PCB
Vertical part lift with height adjustment
Print stroke controlled with rodless cylinder
X/Y/R positioning ware-mounting table
Linear ball bearings on hardened shafts
Squeegee tilt, skew, and height adjustable
Screen frame angle & tilt adjustable
Synchronized bottle inflation system with regulator
Regulated squeegee pressure with pressure gauge
Floor levelers & casters
Foot switch controlled
Specifications of Semi Auto Round Screen Printing Machine:
| Model No.: | AP-600 |
| Drive System: | Pneumatic |
| Frame Up/Down Stroke: | 100mm (3.94″) |
| Maximum Print Area Round: Maximum Print Area Oval: | 180mm (7.08″) Ø 620mm (24.40″) Arc Length |
| Working Table Size: | 250 x 700mm (9.84″ x 27.56″) |
| Table Adjustment: | X,Y ± 15mm / θ 15 ° |
| Maximum Screen Frame Size: | 400 x 800mm (15.75″ x 31.50″) |
| Screen Frame Thickness: | 18 – 25mm (.71″ – .98″) |
| Squeegee Angle: | 0-15° |
| Printing Cycle Speed: | 960 cycles/hr |
| Squeegee Speed: | 16/min |
| Squeegee Pressure: | 2 – 4 Bar |
| Electric Source: | 110V/220V 50-60Hz 50W |
| Air Pressure Input: | 80 psi |
| Air Consumption: | 0.7 L/cycle |
| Net Weight: | 170 kg (374.79 lbs) |
| Gross Weight: | 260 kg (573.20 lbs) |
| Dimensions (L x W x H): | 1,130 x 750 x 1,350mm (44.49″ x 29.53″ x 53.15″) |
| Crate Dimensions: | 1,250 x 940 x 1,460mm (49.21″ x 37″ x 57.48″) |
