Description:
AP-400S screen printing machine specially designed for printing round objects without registration lug (anchor point), such as plastic bottle, sport water bottle, stainless steel container, oil filter, soft tube. etc.
As the bottles or containers do not have registration lug, this AP-400S machine use the optical sensor to read the dot which printed on the first color, as the registraion point. Then use this dot to do multi colors registration.
It can print max bottle diamter to 110mm, easily to changeover for different size bottles on the programmble touch screen. Servo driven rotation and printing stroke, AC motor driven screen frame up/down make the machine operate stably and print accurately.
Features:
- Brand servo driven rotation and printing stroke, AC motor driven up/down stroke.
- Programmble PLC and touch screen controlled all the movements.
- Can do multi colors printing, suits for different kinds of bottle and container printing
- Germany brand optical sensor, high accurtate reading marks.
- Quik and simple tooling changeover
- Floor levelers & casters, Foot switch controlled.
- Squeegee tilt, skew, and height adjustable
Specifications:
| Model NO.: | AP-400S |
| Print shape | Round |
| Up & Down stroke Driven: | Electric motor |
| Print stroke Driven: | Servo motor |
| Re-registration system: | Servo motor & Optical sensor |
| Control system: | Brand PLC & Touch Screen |
| Print round diameter: | Ø7mm(0.276″)-Ø110mm (4.33″) |
| Maximun print area: | L350mm x H220 mm |
| Maximum screen frame size: | 800 x 400mm (31.50″ x 15.74″) |
| Printing cycle speed: | 2000 cycles/hour |
| Registration tolerance: | +/- 0.3-0.5 mm (except products tolerance) |
| Electrical supply: | 110V/220V 50-60Hz 2.5KW |
| Air requirement: | 5-7 bar |
| Machine dimension: | L900 x W800 x H1450 mm |
| Weight: | 200 kg (440.92 lbs) |
