No matter glass bottle printing machine or plastic bottle printing machine are you planning to buy, our automatic round silk screen printing machine is a good choice for you. with our bottle silk screen printing machine, you can sell custom printed glass water bottles, plastic water bottles, screen printed glassware, or provide bottle silk screen printing services.
The AP-100 precise automatic UV container screen printing machines feature a DC motor controlled linear walking beam system that is solidly built to provide accurate color to color print registration with print speeds up to 70 bottles per minute. Either round or oval bottles can be placed into the optional automatic bowl feeder where they are automatically oriented and transported into the UV cured screen printing line. Once bottles enter the AP-100 machinery they are automatically flame treated and fed through each of the subsequent printing and UV curing stations.
Screen Printing On Glass Bottles
Screen Printing On Plastic Bottles
Single Color Round Bottle Screen Printing Machine Video
Advantages of Single Color Round Bottle Screen Printing Machine
1 color automatic UV bottle screen printing machine
Fast print speeds up to 4200 bottles per hour
Accurate color to color registration
Prints on round, oval and square bottles
Mechanical driven bottle transport in high stability
Omron PLC and touch screen controlled
Italy SITI brand main motor
Intelligent UV system saves energy consumption
Integrated anti-static dust blowing and bottle surface flame treating
Specifications of bottle printing machine
| Model NO.: | AP-100-1C |
| Round container size: | Diameter: φ10-100mm, Height: 30-260mm |
| Round container max. print area: | L 260 x W220mm |
| Oval container size: | R: 10-250mm, Height: 30-260mm |
| Oval container max. print area: | L 120 x W220mm |
| Drive: | Mechanical Driven |
| Control system: | OMRON PLC & Touch Screen |
| Max. printing capacity: | 70 pcs/min |
| Registration tolerance: | +/- 0.2 mm |
| Infeed conveyor: | 1 unit, length: 2 meters |
| Deionizing device: | 1 unit |
| Flame treating system: | 1 unit, LP gas |
| Motor: | ITALY MOTOVARIO |
| Print head: | 1 unit |
| UV system: | 1 unit intelligent UV system, 5KW per each |
| Outfeed conveyor: | 1 unit, Length: 2 meters |
| Frequency Converter: | OMRON |
| Pneumatic parts: | FESTO or SMC |
| Electrical: | 380V 3phase 50Hz |
| Air requirement: | 5-7 bar |
| Air consumption: | 85 liter/ minute max. (per color) |
| Power consumption: | 5.4 KW/color x 1 |
| Machine size(LxWxH): | Main machine: 2300x1800x1700mm |
| Weight: | 1600 KG |
*Specifications are subject to change without prior notification
